Stainium / Descaling

Premium abrasive product for descaling operations in wheel-blasting

STAINIUM™ is specially developed for descaling applications when little roughness is required at the end of the process. Specially available in fine grades, STAINIUM™ provides a more stable operating mix.

Buy now

Users benefits

Users benefits

High Efficiency

Unique Blend shot and grit

Premium

Performances

Performances

Efficiency

  • Best solution for descaling operations
  • Increasing your productivity by 10%
  • Improved surface appearance
  • Lower and better-controlled roughness
  • Better surface appearance after cold rolling

Cost-Reduction

  • Reduce the unit cost of your blasting process by 15%
  • Reducing your abrasive consumption by 12% on average
  • Decreasing your reblasting rejects by 15%
  • Reducing your acid pickling process cost
Stainium

Markets and applications

Markets and applications

Special mix of shot & soft grit

Coils & Spring

Surface preparation in Wheelblast machines

Specifications

Specifications



Product name  SM050  SM040  SM030 SM180  SM150  SM140  SM130  SM325 SM318  SM418  SM514
Nominal Size

(Sieve #)

0,30 mm

(#50)

0,42 mm

(#40)

0,60 mm

(#30)

0,18 mm

(#80)

0,18 mm

(#80)

0,35 mm

(#40)

0,50 mm

(#35)

0,71 mm

(#25)

0,85 mm

(#20)

1,00 mm

(#18)

1,40 mm

(#14)

General Shape  Conditioned Mixed of shot and grit
Hardness  46 – 52 HRc
Density  7.3 mini
Chemical Composition  C≥0.80%, Si≥0.4%, 0.6%≤Mn≤1.2%, S≤0.05%, P≤0.05%
Packaging  BOXED BAGS: 1000 kg (2,205 lb) 40 bags of 25 kg (55 lb) per pallet

BIG BAG: 1000 kg (2,205 lb)

DRUM: 1000 kg, 771 kg

Other sizes and specifications available after evaluation. Please contact us for details.

Resources & downloads

Resources & downloads

Leaflet Stainium Brochure

Download

You may also like

You may also like

Premium steel media

This exclusive combination of a Premium Product ensuring better performance than standard products, and a Premium Service to guarantee the optimum use of these products in order to obtain better results in terms of quality and cost, is a pillar of the W Abrasives philosophy.

Profilium

PROFILIUM™ is a very hard “Premium” steel grit, specially developed for speed and consistency on air blasting surface preparation operations. The ready-to-use operational mixture granulometry of the new product simplifies the addition process to obtain a constant and powerful surface profile. In terms of efficiency, PROFILIUM® has no rival on the market. It’s also a high performance alternative to chilled iron.

Discover Profilium
Premium Steel Abrasives

Surfium

Premium quality steel abrasive with a very narrow hardness range (+/- 1.5 RHC) to give a consistent surface profile.

Discover Surfium

Prowheelium

PROWHEELIUM® is a steel grit with a very narrow hardness range for surface preparation before coating, painting, enameling, metallizing. It was developed specially for customers who use GH hardness grit in wheel machines. PROWHEELIUM® considerably reduces machine wear and abrasive consumption.

Discover Prowheelium

HPG

HPG, our Premium cast steel media for foundries, is an angular abrasive specifically designed to improve the cleaning and descaling performance of shot blasting.

Discover HPG

Hybrid Shot

HYBRID SHOT was developed specifically to address new demands for desanding in foundries and descaling in forges and wire drawing plants. By reducing machine wear it helps to reduce maintenance costs while at the same time achieving remarkable performance in terms of cleaning

Discover Hybrid Shot

The W Care approach

The W Care approach

  1. Checking and upgrading equipment adjustments and settings.
  2. Cost reduction offer: assessment of potential advantages, common objective, agreement on prices.
  3. Testing at a Technical Center: validation of the results, winning customer’s confidence, parameter adjustment.
  4. Launching of the industrial test phase: regular monitoring by a technical expert.
  5. Training on site: guarantee of successful project implementation and shared objectives.
  6. Monthly evaluation: monitoring, refining, confirmation of partnership and customer’s commitment.
  7. Assessment of industrial test: evaluation of real benefits, confirmation of expected improvements, extension to other installations, etc.
